Brief:
The HOWO 6 Meter Medical Waste Truck is a specialized vehicle designed for the efficient transportation of medical waste. Built on a sturdy 4X2 drive type, it boasts a wheelbase of 3280mm and measures 5.99 meters in length, 2.17 meters in width, and 3.15 meters in height. With a rated load capacity of 0.865 tons and a total weight of 4.49 tons, it offers ample space for transporting medical waste safely and securely.
Overall, the HOWO 6 Meter Medical Waste Truck combines robust construction, efficient performance, and advanced sterilization features to provide a reliable solution for the transportation of medical waste, ensuring compliance with regulatory standards and promoting public health and safety.
Features:
- Reliable Engine: Powered by a Weichai WP2.3NQ130E61 engine, this medical waste truck delivers a maximum output power of 96 kW (130 horsepower) and torque of 380N·m. Its four-valve, high-pressure common rail, turbocharged intercooled design ensures reliable performance and fuel efficiency.
- Durable Cargo Box: The cargo box measures 4.05 meters in length, 2.1 meters in width, and 2.1 meters in height, providing ample space for storing medical waste. Constructed from stainless steel, it offers durability and corrosion resistance, ensuring the safe transport of hazardous materials.
- Efficient Sterilization System: Equipped with a disinfection lamp and disinfection spray, the upper installation of the vehicle ensures the effective sterilization of the cargo box, maintaining hygiene and preventing the spread of infectious diseases.
- Advanced Transmission: The truck features a Wanliyang 6-speed transmission with 6 gears, offering smooth and efficient gear shifts for enhanced driving comfort and control.
- Sturdy Chassis: Built on a Sinotruk HOWO Light Truck chassis with the Hanjiang series, the vehicle boasts robust construction and reliable performance. With a chassis model of ZZ1047H3315F145Z and a leaf spring configuration of 3/3+2, it provides stability and durability on various terrains.
- Enhanced Safety: Standard configuration includes an ABS anti-lock brake system, ensuring safe and reliable braking performance in all driving conditions.
SPECIFICATIONS:
| Category | Information |
|---|---|
| Basic Information | |
| Drive Type | 4X2 |
| Wheelbase | 3280mm |
| Body Length | 5.99 meters |
| Body Width | 2.17 meters |
| Body Height | 3.15 meters |
| Front Overhang/Rear Overhang | 1.16/1.55 meters |
| Rated Load | 0.865 tons |
| Vehicle Weight | 3.495 tons |
| Total Weight | 4.49 tons |
| Front Wheel Track | 1670mm |
| Rear Wheel Track | 1595mm |
| Maximum Speed | 80 km/h |
| Engine Parameters | |
| Engine Brand | Weichai |
| Engine Model | Weichai WP2.3NQ130E61 |
| Number of Cylinders | 4 cylinders |
| Maximum Output Power | 96 kW |
| Maximum Horsepower | 130 horsepower |
| Displacement | 2.29L |
| Emission Standard | EURO 2, EURO 3, EURO 4, EURO 5 |
| Fuel Type | Diesel |
| Rated Speed | 3200rpm |
| Engine Type | Four-valve, high-pressure common rail, turbocharged intercooler |
| Maximum Torque | 380N·m |
| Cargo Box Parameters | |
| Cargo Box Length | 4.05 meters |
| Cargo Box Width | 2.1 meters |
| Cargo Box Height | 2.1 meters |
| Cargo Box Material | Stainless steel |
| Upper Installation Parameters | |
| Vehicle Announcement | ZZ5047XYYH3315F145 |
| Vehicle Type | Medical waste transfer vehicle |
| Upper Installation Brand | Sinotruk HOWO Light Truck |
| Vehicle Origin | Zhangqiu, Shandong |
| Sterilization Method | Disinfection lamp, disinfection spray |
| Transmission Parameters | |
| Transmission Model | Wanliyang 6-speed |
| Number of Gears | 6 gears |
| Chassis Parameters | |
| Chassis Brand | Sinotruk HOWO Light Truck |
| Chassis Series | HOWO |
| Chassis Model | ZZ1047H3315F145Z |
| Number of Leaf Springs | 3/3+2 |
| Tires | |
| Number of Tires | 6 |
| Tire Specifications | 7.00R16LT 10PR |
| Control Configuration | |
| ABS Anti-lock Brake System | Standard configuration |
