Master Every Mix: Navigate with Confidence, Deliver with Efficiency
The Dayun 3 CBM Construction Mixer Truck is the urban warrior of concrete delivery. This versatile and efficient vehicle tackles demanding construction sites and infrastructure projects with unwavering reliability. Its compact design and advanced features ensure seamless operation, maximizing productivity on every job.
Maneuverability Meets Stability
- 4X2 Drive Train: Offers superior maneuverability in tight urban spaces and navigates various terrains with ease.
- Well-Balanced Overhangs: Optimized front (1.235m) and rear (1.965m) overhangs enhance stability and control during transport.
- 3650mm Wheelbase: Provides a solid foundation for heavy-duty applications, ensuring exceptional load-bearing capacity.
Efficient Transportation, Powerful Performance
- Rated Load Capacity of 7.85 Tons: Allows for efficient transportation of construction materials, minimizing trips and maximizing productivity.
- Yuchai YC4E140-41 Engine: This 4-cylinder powerhouse delivers a robust 140 horsepower (103 kW) while adhering to EURO II-VI emission standards.
- Maximum Speed of 90 km/h: Ensures timely delivery of materials, keeping your project on schedule.
Advanced Mixing Technology, Unmatched Efficiency
- 3.3m³ Mixing Tank Capacity: Facilitates efficient on-site mixing operations.
- Spacious 6m³ Geometric Drum Capacity: Offers ample space for mixing large volumes of concrete or other construction materials.
Operator Comfort, Unwavering Durability
- Comfortable Flat Roof Cab: Provides a spacious and ergonomic workspace for the driver.
- Shao Chi 6J53F Transmission (6 Gears): Delivers smooth acceleration and efficient power transfer.
- Sturdy T3 Creator Series Chassis (STQ1150L03Y2N4): Renowned for its robust construction, this chassis guarantees a safe and reliable driving experience.
- Enhanced Suspension System (8/11+8 Leaf Springs): Offers superior shock absorption and exceptional load-bearing capabilities.
- Durable 9.00R20 Tires: Ensure excellent traction and stability on various road surfaces.
Experience the unmatched efficiency and versatility of the Dayun 3 CBM Construction Mixer Truck. The urban champion built to perform, ensuring a smooth and productive workflow on every project.
SPECIFICATIONS:
| Parameter | Description |
|---|---|
| Drive Type | 4X2 |
| Body Dimensions | 6.85×2.35×3.68 meters |
| Front Overhang/Rear Overhang | 1.235/1.965 meters |
| Wheelbase | 3650mm |
| Rated Load | 7.85 tons |
| Vehicle Weight | 6.53 tons |
| Maximum Speed | 90 km/h |
| Front Wheel Track | 1750mm |
| Rear Wheel Track | 1670mm |
| Engine Parameters | |
| Engine Model | Yuchai YC4E140-41 |
| Fuel Type | Diesel |
| Number of Cylinders | 4 cylinders |
| Maximum Output Power | 103 kW |
| Maximum Horsepower | 140 horsepower |
| Displacement | 4.26L |
| Emission Standard | EURO Ⅱ, EURO Ⅲ, EURO Ⅳ, EURO Ⅴ, EURO Ⅵ |
| Engine Type | Electronic Control Unit Pump, EGR+POC+DOC |
| Upper Installation Parameters | |
| Vehicle Type | Concrete Mixer Truck |
| Upper Installation Brand | CSCTRUCK VanTruckTrailer |
| Mixing Tank Capacity | 3.3m³ |
| Mixing Drum Geometric Capacity | 6m³ |
| Cab Parameters | |
| Cab | Flat Roof |
| Transmission Parameters | |
| Transmission Model | Shao Chi 6J53F |
| Number of Gears | 6 gears |
| Chassis Parameters | |
| Chassis Model | STQ1150L03Y2N4 |
| Chassis Series | T3 Creator |
| Front Axle Description | 151 |
| Rear Axle Description | 153 |
| Number of Leaf Springs | 8/11+8 |
| Tires | |
| Number of Tires | 6 |
| Tire Specifications | 9.00R20 |
