Master the Long Haul, Deliver Freshness Everywhere
The Shacman 9 Meter Refrigerated Truck is the undisputed champion for long-distance transportation of temperature-sensitive goods. This robust and reliable vehicle seamlessly blends power, space, and advanced features to ensure your perishables arrive fresh and on time, no matter the distance.
Powerhouse Performance, Uncompromised Capacity
The Dongfeng Cummins ISB210 40 engine, boasting 210 horsepower and 6 cylinders, delivers the muscle needed to conquer even the most demanding routes. The expansive 8.6 x 2.35 x 2.45 meter cargo box offers unmatched capacity, allowing you to maximize your hauls and optimize your business operations.
Precision Cooling, Guaranteed Freshness
The high-performance Jinda MK858 refrigeration unit maintains precise temperature control within the cargo box. This ensures the quality and freshness of your transported goods are meticulously preserved throughout the journey.
Built to Endure, Engineered for Comfort
The rugged Shaanxi Auto Commercial Vehicle chassis (Xunde X6 series) provides a rock-solid foundation that guarantees stability and unwavering durability, even on unforgiving roads. The spacious and ergonomic cabin prioritizes driver comfort, featuring modern amenities like air conditioning, power windows, and doors, ensuring a relaxed and productive driving experience on long hauls.
Efficiency at its Finest
The 8-speed Fast 8JS85E transmission facilitates smooth gear changes and optimal fuel efficiency, maximizing performance and minimizing operational costs. With features like a sturdy frame structure, advanced braking system, and comprehensive lighting system, safety remains paramount for both driver and cargo.
Quality You Can Trust, Versatility You Need
Manufactured in Suizhou, Hubei, under the strict supervision of CSCTRUCK VanTruckTrailer, this truck adheres to the highest quality standards. The versatile suspension system offers a variety of leaf spring configurations (9/9/10+8, 9/9/10+6, etc.) to cater to diverse load requirements and road conditions.
Experience the unwavering performance and unmatched reliability of the Shacman 9 Meter Refrigerated Truck. Choose the champion for long-haul chilled deliveries and redefine the boundaries of fresh transport.
SPECIFICATIONS
| Category | Description |
|---|---|
| Drive Type | 6X2 |
| Wheelbase | 1800+5500mm |
| Body Dimensions | 11.05×2.55×3.995 meters |
| Front Overhang/Rear Overhang | 1.45/2.8 meters |
| Rated Load | 15.3 tons |
| Vehicle Weight | 9.505 tons |
| Front Wheel Track | 1910/1910mm |
| Rear Wheel Track | 1860mm |
| Maximum Speed | 95km/h |
| Notes | Spare tire, air conditioning, power windows and doors |
| Engine Parameters | |
| Engine Model | Dongfeng Cummins ISB210 40 |
| Number of Cylinders | 6 cylinders |
| Maximum Output Power | 155 kW |
| Maximum Horsepower | 210 horsepower |
| Displacement | 5.9L |
| Emission Standard | EURO Ⅱ, EURO Ⅲ, EURO Ⅳ, EURO Ⅴ, EURO Ⅵ |
| Fuel Type | Diesel |
| Rated Speed | 2500rpm |
| Engine Type | |
| Maximum Torque | |
| Cargo Box Parameters | |
| Cargo Box Dimensions | 8.6×2.35×2.45 meters |
| Cargo Box Length | 8.6 meters |
| Cargo Box Width | 2.35 meters |
| Cargo Box Height | 2.45 meters |
| Upper Installation Parameters | |
| Vehicle Type | Refrigerated Truck |
| Upper Installation Brand | CSCTRUCK VanTruckTrailer |
| Refrigeration Unit | Jinda MK858 Refrigeration Unit Model |
| Cab Parameters | |
| Cab | |
| Transmission Parameters | |
| Transmission Model | Fast 8JS85E |
| Number of Gears | 8 gears |
| Chassis Parameters | |
| Chassis Brand | Shacman |
| Chassis Model | SX1254GP4 |
| Frame Dimensions | 280/8+6 double layer mm |
| Front Axle Description | |
| Rear Axle Description | 153 rear axle |
| Speed Ratio | 5.135 |
| Number of Leaf Springs | 9/9/10+8, 9/9/10+6, 9/9/10+3, 10/10/10+8, 10/10/10+3, 3/3/4+3 |
| Tires | |
| Number of Tires | 8 |
| Tire Specifications | 10.00R20 |
