Freshness Delivered, Efficiency Achieved
The Foton 6 Meter Reefer Van Truck is the perfect blend of versatility, efficiency, and performance, making it the ideal choice for transporting temperature-sensitive goods in the food, pharmaceutical, and logistics industries. This reliable vehicle ensures your perishables arrive fresh and on time, every time.
Built to Endure, Engineered for Efficiency
The Foton 6 Meter Reefer Van Truck features a sturdy chassis by Foton Commercial Vehicle, guaranteeing stability and durability for even the heaviest loads. Navigate any road with confidence, knowing your cargo is secure.
Precision Cooling, Guaranteed Freshness
The specialized Hanxue refrigeration unit is the heart of this truck’s cooling system. This advanced unit maintains precise temperature control, ranging from -18°C to 8°C, ensuring the optimal environment for your most delicate perishables. Features like temperature upper and lower limit control, automatic start/stop, and both automatic and manual defrosting provide unmatched flexibility and control over the cooling process.
Powerhouse Performance, Eco-Conscious Operation
The Foton BJ486EQV4 engine, developed by Foton Environmental Protection Power, delivers impressive power (129 horsepower) and torque (186 N·m) while adhering to EURO IV emission standards. This translates to efficient operation and a minimized environmental impact.
Spacious Capacity, Diverse Applications
The 2.75 x 1.41 x 1.39 meter cargo box offers a generous 5 cubic meters of space, perfect for transporting a wide variety of cargo sizes. This versatility makes the Foton 6 Meter Reefer Van Truck ideal for diverse applications within the chilled goods transportation sector.
Seamless Operation, Total Control
The 5-speed gearbox facilitates smooth and efficient gear changes, optimizing overall performance and fuel efficiency. The CSCTRUCK VanTruckTrailer upper installation of the refrigeration unit guarantees quality and reliability, while the comprehensive dashboard with temperature monitoring allows for real-time monitoring and adjustment of cooling settings directly from the cab. Combined with a maximum speed of 135 km/h, you can ensure timely deliveries while maintaining complete control over your cargo’s environment.
Experience the unmatched versatility and efficiency of the Foton 6 Meter Reefer Van Truck. Choose the reliable champion for chilled deliveries and elevate your cold chain operations to the next level.
SPECIFICATIONS:
| Parameter | Description |
|---|---|
| Wheelbase | 2890mm |
| Body Dimensions | 5.32×1.69×2.465 meters |
| Front Overhang/Rear Overhang | 1.320/1.100 meters |
| Rated Load | 0.82 tons |
| Vehicle Weight | 1.9 tons |
| Front Wheel Track | 1460mm |
| Rear Wheel Track | 1440mm |
| Maximum Speed | 135 km/h |
| Engine Parameters | |
| Engine Brand | Foton Environmental Protection Power |
| Engine Model | Foton BJ486EQV4 |
| Number of Cylinders | 4 cylinders |
| Maximum Output Power | 95 kW |
| Maximum Horsepower | 129 horsepower |
| Displacement | 1.998L |
| Emission Standard | EURO IV |
| Engine Type | Inline four-cylinder, dual overhead camshaft, intake VVT technology |
| Maximum Torque | 186N·m |
| Cargo Box Parameters | |
| Cargo Box Dimensions | 2.75×1.41×1.39 meters |
| Cargo Box Length | 2.75 meters |
| Cargo Box Width | 1.41 meters |
| Cargo Box Height | 1.39 meters |
| Box Volume | 5m³ |
| Upper Installation Parameters | |
| Vehicle Type | Refrigerated Truck |
| Upper Installation Brand | CSCTRUCK VanTruckTrailer |
| Location of Entire Vehicle Production | Suizhou |
| Refrigeration Temperature | -18°C |
| Refrigeration Unit | Hanxue refrigeration unit with temperature upper and lower limit control, automatic start and stop, automatic and manual defrosting, fault alarm, hot air defrosting system. Temperature range: adjustable from 2°C to 8°C, including temperature monitoring device (adjustable from the driver’s cab) |
| Transmission Parameters | |
| Transmission Model | 5-speed gearbox |
| Number of Gears | 5 gears |
| Chassis Parameters | |
| Chassis Brand | Foton Commercial Vehicle |
| Chassis Series | Foton Scenery |
| Chassis Model | BJ5036XLC-XB |
| Number of Leaf Springs | -/4+1 |
| Tires | |
| Number of Tires | 4 |
| Tire Specifications | 185R14C |
