Master the Distance, Deliver Freshness Uncompromised
The Foton 10 Meter Refrigerated Box Truck sets the bar for long-haul refrigerated transport. Engineered with meticulous precision and equipped with industry-leading features, this powerhouse delivers exceptional performance, unwavering reliability, and efficient operation, ensuring your temperature-sensitive cargo arrives fresh and on time, on every single trip.
Maneuverability Meets Stability, Efficiency Meets Sustainability
The 4X2 drive configuration provides the perfect balance of maneuverability on various road conditions and unwavering stability for long-distance journeys. Under the hood, the Foton Cummins ISF3.8S5168 engine, featuring a 3.76L turbocharged intercooled design, delivers exceptional performance while adhering to EURO II, III, IV, V, and VI emission standards. Experience power, efficiency, and environmental responsibility, all in one.
Spacious Capacity, Precision Cooling
The expansive 6.72 x 2.32 x 2.315 meter cargo box offers ample space to maximize your hauls. The Jinda MK858 refrigeration unit maintains precise temperature control within the compartment, safeguarding the freshness and quality of your most delicate perishables throughout even the longest journeys.
Seamless Operation, Unwavering Durability
The Fast 8JS75TB 8-speed transmission ensures smooth gear shifting and efficient power delivery, while the sturdy Foton BJ1166VJPEN-1 chassis provides a rock-solid foundation for heavy-duty transportation. The 5250mm wheelbase optimizes load distribution and handling characteristics, further enhancing stability and control.
Built for Speed, Engineered for Efficiency
The 10 Meter Refrigerated Box Truck boasts a maximum speed of 90 km/h, ensuring timely deliveries over long distances. Six 9.00R20 tires provide excellent traction and durability for long-haul journeys, while the optimized front (1.35 meters) and rear overhang (2.76 meters) contribute to balanced weight distribution and superior handling.
High Payload Capacity, Uncompromising Safety
With a rated load capacity of 8.34 tons and a vehicle weight of 7.26 tons, this truck offers an impressive payload-to-weight ratio, maximizing your hauling potential without compromising structural integrity. The ergonomically designed cabin prioritizes driver comfort and convenience, while advanced safety features ensure the well-being of both driver and cargo throughout the journey.
Experience the unmatched performance and unwavering reliability of the Foton 10 Meter Refrigerated Box Truck. Choose the long-haul champion for precision-cooled deliveries and redefine the boundaries of fresh transport.
SPECIFICATIONS:
| Parameter | Description |
|---|---|
| Drive Type | 4X2 |
| Wheelbase | 5250mm |
| Body Dimensions | 9.115×2.49×3.765 meters |
| Front Overhang/Rear Overhang | 1.35/2.76 meters |
| Rated Load | 8.34 tons |
| Vehicle Weight | 7.26 tons |
| Front Wheel Track | 1810mm |
| Rear Wheel Track | 1907mm |
| Maximum Speed | 90km/h |
| Engine Parameters | |
| Engine Model | Foton Cummins ISF3.8S5168 |
| Number of Cylinders | 4 cylinders |
| Maximum Output Power | 125 kW |
| Maximum Horsepower | 168 horsepower |
| Displacement | 3.76L |
| Emission Standard | EURO II, EURO III, EURO IV, EURO V, EURO VI |
| Engine Type | Inline 4-cylinder, direct injection, turbocharged intercooled, electronically controlled common rail |
| Cargo Box Parameters | |
| Cargo Box Dimensions | 6.72×2.32×2.315 meters |
| Cargo Box Length | 6.72 meters |
| Cargo Box Width | 2.32 meters |
| Cargo Box Height | 2.315 meters |
| Upper Installation Parameters | |
| Vehicle Type | Refrigerated Truck |
| Upper Installation Brand | CSCTRUCK VanTruckTrailer |
| Refrigeration Unit | Jinda MK858 |
| Transmission Parameters | |
| Transmission Model | Fast 8JS75TB |
| Number of Gears | 8 gears |
| Chassis Parameters | |
| Chassis Brand | Foton |
| Chassis Model | BJ1166VJPEN-1 |
| Rear Axle Description | 1153 |
| Speed Ratio | 5.833 |
| Number of Leaf Springs | 8/10+8 |
| Tires | |
| Number of Tires | 6 |
| Tire Specifications | 9.00R20 |
